SEQUEL S2

OVERVIEW

SEQUEL S2

Price¥143,000（税込価格）

  • Size 15", 17", 19", 21", 23"
  • Frame Size Specific Design frame geometry, Reynolds 520 double-butted chromoly main tubes, threaded BB shell, chain stay flat mount disc brake mounts, 12mm thru-axle, FD mount, dropper post ready, 3 waterbottle mounts, TT mounts, rack and fender eyelets
  • Fork Jamis Chromoly fork, 12mm dropouts, 45mm crown, IS mount disc brakes, fender, lowrider and water bottle eyelets
  • Components Shimano SLX M7000
  • Brakeset Shimano BR-MT400 hydraulic disc brakes with resin pads, Shimano 160mm stainless 6-bolt rotors with Shimano BL-MT401 levers
  • Wheels WTB STX i25 TCS (UST Tubeless Compliant System) disc rims, 32H, Formula alloy 6-bolt sealed bearing rear hub, 14g black stainless steel spokes and front 12mm/rear 12x142 thru-axle with Switch Lever
  • Tires WTB Byway Tire with DNA compound, 650 x 47c
  • Weight -
  • REYNOLDS
  • SSD

SPECIFICATIONS

Model SEQUEL S2
Price ¥143,000
Frame Size Specific Design frame geometry, Reynolds 520
double-butted chromoly main tubes, threaded BB shell, chain stay flat mount disc brake mounts, 12mm thru-axle, FD mount, dropper post ready, 3 waterbottle mounts, TT mounts, rack and fender eyelets
Fork Jamis Chromoly fork, 12mm dropouts, 45mm crown, IS mount disc brakes, fender, lowrider and water bottle eyelets
Headset FSA IS3 Internal headset 1 1/8"
Wheels WTB STX i25 TCS (UST Tubeless Compliant System)
disc rims, 32H, Formula alloy 6-bolt sealed bearing rear hub, 14g black stainless steel spokes and front 12mm/rear 12x142 thru-axle with Switch Lever
Tires WTB Byway Tire with DNA compound, 650 x 47c
Derailleurs Shimano Deore RD-M4120 GS Shadow Plus rear
Shift levers Shimano Deore RapidFire Plus SL-M4100, 10-speed
Chain KMC X10
Cassette Sunrace CSMS2, 10-Speed 11-42T
Crankset FSA Velo Pro Crank, 40T MegaTooth, 165mm(15/17"), 170mm(19/21"), 175mm(23)
BB Set FSA sealed cartridge, 68×110.5mm
Pedals Platform style, alloy
Brakeset Tektro HD-M280/281 hydraulic Flat Mount disc brakes with 160mm rotors and Tektro brake levers. 15-17" M281 (83mm reach); 19-23" M280 (88mm reach)
Handlebar Jamis Riser bar, aluminum, 10° sweep, 3° up sweep, 20mm rise, 31.8 x 680mm (15/17/19") 700mm (21/23")
Stem Jamis, 3D forged alloy, 3° rise, Length-40mm (15/17"), 50mm (19/21"), 60mm (23")
Grips MTB Kraton/Gel Double Density Grip Lock-on
Seat Post Jamis alloy micro-adjust, 27.2 x 350mm alloy clamp with QR seatpin
Saddle Vivo Ergo Saddle A062HRN
Size 15", 17", 19", 21", 23"
Color Riptide

FIT & SIZING

ジオメトリ表
  • A = SEAT TUBE
  • B = EFFECTIVE TT LENGTH
  • C = HEAD TUBE ANGLE
  • D = SEAT TUBE ANGLE
  • E = CHAINSTAY
  • F = WHEELBASE
  • G = FORK RAKE
  • H = BOTTOM BRACKET DROP/HEIGHT
  • I = HEAD TUBE
  • J = STANDOVER
  • K = STACK
  • L = REACH
MODEL SEQUEL S2
SIZE 15 17 19 21 23
inch inch inch inch inch
ASEAT TUBE 390 430 470 510 550
BEFFECTIVE TT LENGTH 550 583 600 615 643
CHEAD ANGLE 71° 71° 71.5° 71.5° 71.5°
DSEAT ANGLE 74.5° 74.5° 73° 73° 73°
ECHAIN STAY 435 440 445 450 450
FWHEEL BASE 1047 1086 1088 1109 1140
GFORK RAKE 53 53 50 50 50
HBB DROP 70 70 65 65 60
IHEAD TUBE 90 120 150 180 210
JSTAND OVER 706 740 777 812 849
KSTACK 531 559 586 614 638
LREACH 403 428 421 427 448
REAR OLD 142 142 142 142 142
